RS-1 Placement Solution
RS-1 Placement Solution

JUKI's RS-1 stands for next generation equipment!

The flexible all-rounder simplifies product change, increases productivity and contributes to an ideal load factor. A revolutionary placement head with a unique design offers a high degree of flexibility and is for sure a secure investment for future production requirements.

Class leading speed, up to 42,000 CPH

Maximum speed of up to 42,000 CPH. This is possible due to a revolutionary head design that reduces travel time and distance for every placement.

New RF feeders are smaller, thinner and lighter

The new RF feeders are 17 % smaller and 50 % lighter, but still maintain the same high degree of positional accuracy. The thinner width allows up to 112 feeder inputs.

Wide component range

RS-1 supports components from 0201 (metric) up to 74 mm square or 50 × 150 mm rectangular parts. The RS-1 component height goes up to 25 mm.

Optimum line balance and highest throughput on any product

Changing the RS-1 functionality does not require a head replacement. The revolutionary head design adjusts automatically to the production requirements. It can be used in-line with high speed chip placement machines to improve overall line productivity or to make the line more flexible for complex PCBs with a high number of large components.

New Head Design

The RS-1 new head design automatically adjusts the height according to the height of components to be placed next. This technology reduces the Z travel distance to the required minimum, allowing an increase of throughput to a maximum regardless of the product.
